A Lab Mixer operates by imparting mechanical energy to the material being mixed, promoting uniform blending of components within a container. The core mechanism involves a motor-driven shaft connected to mixing tools such as paddles, blades, or propellers, which rotate at variable speeds to agitate and combine substances efficiently.
When the motor is switched on, it drives the shaft and attached mixing tool(s), creating fluid motion within the vessel. Depending on the mixer type and attachment:
- Overhead mixers use blades or impellers that generate shear forces and turbulence, breaking down agglomerates and ensuring thorough mixing.
- Planetary mixers rotate the mixing tool around its own axis while simultaneously revolving around the mixing bowl, creating a sweeping and kneading action ideal for viscous and sticky materials.
The speed of rotation and the design of the mixing tool determine the intensity and nature of mixing, allowing the lab mixer to handle a wide range of materials from low-viscosity liquids to high-viscosity pastes.
The process continues until a homogenous mixture is achieved, with no visible segregation or unevenness. Many lab mixers offer adjustable speed controls, enabling users to optimize mixing for specific applications and material characteristics.
Specification | Details |
Model | LM-5 to LM-50 |
Mixing Capacity | 5 L to 50 L |
Speed Range | 100 – 2000 RPM (Variable) |
Motor Power | 0.5 HP to 3 HP |
Voltage | 220V / 110V, 50/60 Hz |
Mixer Type | Overhead / Planetary (optional) |
Material Construction | Stainless Steel (SS304/SS316) |
Mixing Tools Included | Paddle, Propeller, Blade ,Anchor , Cowl |
Control Interface | Analog dial / Digital display |
Heating/Cooling Jacket | Available (Steam/Thermic/Chilled Water) |
Surface Finish | Mirror Polish (Ra < 0.4 µm), Matte Polish (Ra < 0.8 µm)GMP-compliant |
Noise Level | < 60 dB |
Safety Features | Overload protection, E-stop |
Optional Accessories | Temperature control, Timer, loadcell |
- Compact Design: Space-saving footprint ideal for laboratory benches and fume hoods.
- Variable Speed Control: Adjustable speed from 100 to 2000 RPM to suit different mixing requirements.
- Robust Construction: High-grade stainless steel body and mixing tools ensure long-term durability and corrosion resistance.
- Interchangeable Mixing Tools: Includes paddle, propeller, and blade attachments for optimized mixing of various materials.
- Digital Speed Display: Easy-to-read digital panel for precise speed monitoring (available in advanced models).
- Safety Features: Overload protection and emergency stop button for operator safety.
- Quiet Operation: Low noise output enables comfortable lab working conditions.
- Pharmaceutical R&D and quality control
- Cosmetic formulation and testing
- Food and beverage product development
- Chemical synthesis and analysis
- Material science and polymer blending
