Key Features
Applications
Technical Specifications
Key Features
- No Heat Generation – Ideal for thermally sensitive materials
- No Moving Mechanical Parts – Ensures low maintenance and long machine life
- High Fineness Range – Achieves particle sizes as low as 1–10 microns
- GMP & CIP Compliant Design – Suitable for pharmaceutical, food, and cosmetic applications
- Highly Efficient Classification System for consistent particle size
- Inert Gas Compatibility for handling explosive or oxygen-sensitive materials
Applications
- Pharmaceuticals: API micronization, antibiotics, and steroids
- Cosmetics: Fine powders for makeup and skincare
- Food & Nutraceuticals: Natural extracts, flavors, enzymes
- Chemicals: Pigments, polymers, and specialty chemicals
- Aerospace & Electronics: High-purity materials and additives
Technical Specifications
Model | Capacity (kg/hr) | Particle Size Range | Compressed Air Pressure | Air Consumption (m³/min) | Material of Construction | Feed Size (mm) |
JBM-JM-50 | 1 – 10 | 1 – 25 µm | 6 – 8 bar | 2 – 3 | SS316 / GMP Grade | < 2 mm |
JBM-JM-100 | 10 – 25 | 1 – 25 µm | 6 – 8 bar | 4 – 5 | SS316 / GMP Grade | < 2 mm |
JBM-JM-200 | 25 – 50 | 1 – 25 µm | 6 – 8 bar | 6 – 8 | SS316 / GMP Grade | < 2 mm |
JBM-JM-500 | 50 – 150 | 1 – 25 µm | 6 – 8 bar | 10 – 12 | SS316 / GMP Grade | < 2 mm |
