Key Features
- Hemisphere-bottom design for complete mixing and uniform heat distribution
- Jacketed vessel for steam, hot water, or oil-based indirect heating
- Available with mechanical or anchor-type agitator (optional)
- Tilting mechanism or bottom discharge valve for easy unloading
- Built with SS316 / SS316L contact parts (GMP-compliant)
- Optional temperature indicators, insulation, and control panels
- Easy to clean with CIP/WIP compatibility
Applications
- Pharmaceutical: Binder paste for granulation, starch gel
- Food: Sauces, syrups, starch solutions
- Cosmetic: Cream bases, waxes, emulsions
- Chemical: Gels, adhesives, resins preparation
- Herbal: Plant-based pastes, decoctions
Technical Specifications
Parameter | Specification |
Capacity | 25 L to 600 L (Customizable) |
Material of Construction | SS316 / SS316L (Product Contact), SS304 (Non-contact) |
Heating Type | Steam / Hot Water / Thermic Fluid |
Temperature Range | Ambient to 100°C (or higher as required) |
Agitator Type | Optional – Anchor / Paddle / Mechanical Stirrer |
Tilting Mechanism | Manual or Motorized (Optional) |
Discharge Valve | Bottom Nozzle / Flush Valve / Butterfly Valve |
Jacket Pressure Rating | Up to 3 bar (as per design) |
Insulation | Mineral Wool / Glass Wool with SS cladding |
Control Panel | Optional Digital or PLC-HMI Based |
Certifications | GMP / CE / ATEX (Optional) |
