Key Features
- Uniform Particle Size Distribution for enhanced product quality and process consistency
- Low Energy Milling with minimal heat generation, ideal for heat-sensitive materials
- Interchangeable Screens and Rotors for flexibility in product range and process optimization
- Compact and GMP-Compliant Design with easy-to-clean components for hygienic operations
- Continuous or Batch Processing Modes based on process needs
- Robust Stainless Steel Construction for durability and contamination-free operation
Applications
- Milling of dry or wet granules in pharmaceutical formulations
- De-agglomeration and post-granulation sizing in food and nutraceuticals
- Preparation of uniform powders in cosmetic and personal care products
- Size reduction of chemicals and intermediates in industrial applications
Technical Specifications
Model | Output Capacity | Screen Diameter | Motor Power | Rotor Speed (RPM) | Material of Construction | Screen Types |
JBM-CM-100 | 50 – 150 kg/hr | 100 mm | 2 HP | 500 – 1500 | SS304 / SS316 | Round / Square / Slotted |
JBM-CM-200 | 100 – 300 kg/hr | 200 mm | 5 HP | 500 – 1500 | SS304 / SS316 | Round / Square / Slotted |
JBM-CM-300 | 200 – 600 kg/hr | 300 mm | 7.5 HP | 500 – 1500 | SS304 / SS316 | Round / Square / Slotted |
JBM-CM-500 | 400 – 1000 kg/hr | 500 mm | 10 HP | 500 – 1500 | SS304 / SS316 | Round / Square / Slotted |
