Sigma Mixer
The Sigma Mixer, also known as a Dough Mixer, is a heavy-duty industrial mixer specifically designed for kneading, mixing, and homogenizing highly viscous materials, pastes, and dough-like substances. It features a horizontal U-shaped trough with two counter-rotating sigma-shaped blades that provide powerful shearing and folding action for efficient and thorough mixing.
This mixer is ideally suited for processing sticky, semi-solid, or high-viscosity materials commonly found in the pharmaceutical, food, rubber, chemicals, adhesives, and plastic industries.
- Sigma-Shaped Blades: High shear action ensures intense mixing and kneading.
- Robust Construction: Built for heavy-duty, continuous operation.
- Jacketed Bowl (Optional): For heating or cooling during mixing.
- Tilting Mechanism / Bottom Discharge: Easy product removal and cleaning.
- Multiple Blade Configurations: Sigma, double sigma, or Z-blades to suit application.
- Variable Speed (Optional): Controlled via VFD for process flexibility.
- Dough mixing for bakery and food products
- Rubber and plastic compounding
- Adhesives and sealant blending
- Pharmaceutical wet mass and ointments
- Pigments, ink, and printing pastes
- Soap and detergent production
Specification | Details |
Model | SM-50 / SM-300 / SM-1000 / Custom |
Mixing Capacity | 20 – 3000 Liters |
Blade Type | Sigma / Z / Double Arm |
Rotation Speed | 10 – 60 RPM (variable speed optional) |
Material of Construction | SS304 / SS316 / Carbon Steel |
Trough Type | Fixed / Tiltable |
Discharge | Tilting / Bottom Valve / Screw Discharge |
Drive Mechanism | Gearbox with motor (Heavy-duty design) |
Jacketed Bowl | For heating/cooling (Steam, Water, Oil) |
Finish Type | Mirror / Matt / Bead Blasted |
Optional Features | Load cells, PLC control, temperature sensors |
